Normio Locking Plate M8, 2 Tabs

2,25 EUR

Incl. 19% VAT.

Description

Galvanized locking plate with 2 tabs for securing screws and nuts.

Take the following measurements from Figure 2:

  • d1: 8.4 mm
  • d2: 17 mm
  • b: 8 mm
  • h: 11 mm
  • h1: 20 mm
  • s: 0.75 mm

A high-quality product from the Normio brand for select industrial components with high standards for precision, durability, and manufacturing quality.

ManufacturerNormio
MaterialSteel
Surfacegalvanized (blue)
Thread sizeM8
Width8 mm
Nominal diameter (thread)8 mm
Number of lobes2 pcs
Ø inside8.4 mm
Ø outside17 mm
Total length11 mm
Thickness0.75 mm
Length 220 mm
Width 28 mm
