Motor cable routing | Z50

swiing® revival cable guide mudguard black | Puch

Manufacturer: swiing® revival parts · Total length: 74 mm · Height: 12.5 mm · Material: Plastic · Color: black · Mounting type: Plug connection · Number of fixing points: 2 pcs · Hole spacing: 63 mm

swiing® revival gasket set Z50 engine | Puch X30 NS / NL

Manufacturer: swiing® revival parts · Material: Sealing paper · Area of application: Standard · Ø outlet inside: 22 mm · Hole pattern [mm]: 44 x 44 · Hole spacing inlet: 32 - 38 mm · Hole spacing outlet: 42 mm · Number of components: 10 pcs

Oil filler plug with sealing ring | Puch Maxi

Material: Steel · Surface: galvanized (blue) · Drive: Slot · Total length: 14.6 mm · Thread type: M10x1.5 (standard thread) · Thread length: 6 mm · Screw head: Lens head · Ø External head: 14 mm · Number of components: 2 pcs · Puch OEM number: 364.1.10.660.1

Tank cap lockable high version | Puch Maxi N

Material: Plastic · Color: black · Fuel filler cap: Plug 30 mm · Lockable: Yes

GPO gasket cylinder base 0.35 mm original | Puch

Manufacturer: GPO · Place of use: Cylinder base · Material: Oiled paper · Area of application: Standard · Nominal diameter: 47 mm · Ø inside: 47 mm · Thickness: 0.3 mm · Hole pattern [mm]: 44 x 44 · Puch OEM number: 349.3.10.013.1

swiing® revival gearbox cover gasket (old model) | Puch Z50 engine

Manufacturer: swiing® revival parts · Material: Sealing paper · Color: sand-colored · Total length: 166 mm · Width: 155 mm · Number of fixing points: 8 pcs · Thickness: 0.35 mm · Number of components: 1 pcs

Bride cable original | Piaggio SI

Manufacturer: Piaggio · Ø mounting hole: 7.15 mm

Petrol hose Ø 5 / 7 mm transparent 30 cm (1A quality)

Manufacturer: Made in Italy · Ø inside: 5 mm · Color: transparent · Ø outside: 7 mm · Total length: 300 mm

Cable routing Bowden cable

Material: Aluminum · Ø inside: 0 - 8 mm · Width: 20.5 mm
