Air filter 20 mm | Sachs 504, 505, 535 (A4209)

Bing 85/12/101 carburetor (replica) | Sachs 504, 505, 508, 535

Nominal diameter: 12 mm · Material: Aluminum · Component group Carburetor: Carburetor complete · Carburetor type: 85 · Ø fuel hose connection: 6 mm · Width: 50 mm · Ø Inside entrance: 12 mm · Ø Internal connection: 20 mm · Ø Output inside: 12 mm · Mounting type: Plug connection clamped · Air filter connection thread: M5x0.8 (standard thread) · Total length: 48 mm · Mixed oil connection: No · Vacuum connection: No · Height: 100 mm · Choke control: without choke · Nozzle thread: M4x0.7 (standard thread) · Camouflaged: No · Nozzle size: 52 · Area of application: Standard

Clamp air filter box Sachs 504 (A4238)

Material: Steel · Surface: galvanized (blue)

Air filter box rear original | Sachs 504, 505, 535

Material: Plastic · Color: black · Area of application: Original

Original front air filter box | Sachs 504, 505, 535 (A4209)

Material: Plastic · Color: black · Area of application: Original · Area of application: Standard

BING 85/8/101 carburetor NOS | Sachs 504, 535

Nominal diameter: 8 mm · Manufacturer: BING · Component group Carburetor: Carburetor complete · Carburetor type: 85 · Ø fuel hose connection: 6 mm · Ø Internal connection: 20 mm · Mounting type: Plug connection clamped · Air filter connection thread: M5x0.8 (standard thread) · Nozzle thread: M4x0.7 (standard thread) · Nozzle size: 48 · Area of application: Original

Air filter insert Ø 26 mm Racing | Sachs 503 AB/ABL, 504 CH (A4336)

Material: Paper · Area of application: Tuning · Ø inside: 28 mm · Ø outside: 49 mm · Total length: 58 mm · Color: black · Color: yellow · Width: 58 mm · Height: 64.2 mm · Camouflaged: No · Alternative version of the Pony OEM number: A4336 · Alternative version of the Sachs OEM number: 0225 010 100

Rear air filter box NOS | Sachs 504 / 505 / 535

Manufacturer: Sachs · Material: Plastic · Area of application: Original · Color: black

Air filter 16 mm original | Sachs 504, 505, 535 (A4209)

Material: Plastic · Color: black · Mounting type: Screws · Width: 57 mm · Height: 57 mm · Filter type: Standard sieve · Total length: 173 mm · Ø Internal connection: 14.5 mm · Pony OEM number: A4209

CAWI fuel filler cap bayonet 40 mm

Ø External head: 64.8 mm · Manufacturer: CAWI · Material: Steel · Surface: chrome-plated · Color: Chrome · Fuel filler cap: Bayonet 40 mm · Lockable: No · Vented: Yes · Height: 23.4 mm

GPO flywheel trigger M26x1.5 / M22x1.5 | Puch, Sachs, Tomos, Beta 521

Width across flats trigger: 27 mm · Width across flats Screw: 19 mm · Manufacturer: GPO · Clamping depth: 10 mm · Area of application: (Dis)assembly tool · Material: Steel · Surface: blackened · Total length: 55 mm · Total length: 75 mm · Strength class: 8.8 · Number of components: 1 pcs · Thread type: MF22x1.5 (fine pitch thread) · Thread type: MF26x1.5 (fine pitch thread)

Outlet seal Ø 27 Steel ring

Material: Sealing carton · Material: Sheet metal (steel) · Area of application: Tuning · Reinforced: Yes · Ø outlet inside: 27 mm · Ø screw holder: 6.3 mm · Place of use: Outlet · Hole spacing outlet: 42.5 mm · Thickness: 2.1 mm

Gas cable Ø 1.25 mm x 220 cm (cylindrical nipple) Bing

Ø nipple: 3 mm · Nipple length: 5 mm · Manufacturer: Made in Germany · Area of application: Standard · Material: Steel · Surface: galvanized (blue) · Ø Stranded wire: 1.25 mm · Nipple shape: Cylinder · Cable length: 2200 mm · Number of components: 1 pcs

OMG fuel filter metal 6 mm (removable)

Manufacturer: OMG · Material: Glass · Material: Metal · Color: gray · Color: transparent · Color: white · Filter type: Plastic net · demountable: Yes · Total length: 40 mm · Total length: 63 mm · Ø inside: 3.45 mm · Ø fuel hose connection: 5.6 mm · Ø fuel hose connection: 6 mm · Ø outside: 22 mm

Fuel tap horizontal M12x1 (with union nut) outgoing at the bottom

Possible lever positions: open / closed / reserve · Material lever: Metal · Filter type: Plastic net · Ø fuel hose connection: 6 mm · Installation direction: horizontal / horizontal · Outlet direction: below · Spare tube shape: curved · Mounting type: Union nut · Reserve level: 70 mm · Thread type: MF12x1 (fine pitch thread)

GPO rubber for swingarm mounting | Puch Maxi S, X30

Ø inside: 24 mm · Manufacturer: GPO · Material: Rubber · Color: black · Ø outside: 32 mm · Ø outside: 37 mm · Total length: 90 mm · Puch OEM number: 349.1.21.509.1

Motorex Automatic Motor Oil (ATF) 450 ml

Manufacturer: Motorex · Area of application: Gearbox lubrication with clutch · Contents: 450 ml · Gearbox type: Automatic machine · Temperature resistance (min.): -45 - 200 °C · Pony OEM number: A2080 · Sachs OEM no.: 0263 014 002

swiing® revival air filter screen Ø 52 mm original

Manufacturer: swiing® revival parts · Camouflaged: No · Area of application: Standard · Material: Steel · Surface: galvanized (blue) · Color: silver · Height: 10 mm · Ø outside: 52 mm

Bing 85/13/101 carburetor (replica) | Sachs 504, 535

Material: Aluminum · Component group Carburetor: Carburetor complete · Width: 50 mm · Carburetor type: 85 · Nominal diameter: 13 mm · Total length: 48 mm · Ø fuel hose connection: 6 mm · Ø Inside entrance: 13 mm · Ø Internal connection: 20 mm · Ø Output inside: 13 mm · Air filter connection thread: M5x0.8 (standard thread) · Mixed oil connection: No · Vacuum connection: No · Choke control: without choke · Nozzle thread: M4x0.7 (standard thread) · Camouflaged: No · Nozzle size: 52
