Stud bolt inlet/outlet M7/8 x 30 mm

Main stand black (budget) | Puch Maxi S, P1 / X30 NS, NL, NG

Material: Steel · Surface: varnished · Stand base - center mount (A): 207 mm · Color: black · Total width of stand base (B): 217 mm · Wide receptacle (C): 66 mm · Ø Receptacle (D): 18 mm · Spring nipple distance - center pivot axis (E): 75 mm · Total height: 220 mm · Wide upright foot (F): 20 mm · Wide upright foot (F): 50 mm

swiing® revival upright spring blue galvanized | Puch

Spring design: Tension spring · Length spring hook: 19 mm · Length spring hook: 53 mm · Ø wire: 2.5 mm · Manufacturer: swiing® revival parts · Material: Spring steel · Surface: galvanized (blue) · Ø inside: 9 mm · Ø outside: 14 mm · Total length: 122 mm

Fuel tap horizontal M12x1 (with union nut) outgoing at the bottom

Manufacturer: GPO · Possible lever positions: open / closed / reserve · Material lever: Metal · Thread type: MF12x1 (fine pitch thread) · Filter type: Plastic net · Ø fuel hose connection: 6 mm · Installation direction: horizontal / horizontal · Outlet direction: below · Spare tube shape: curved · Mounting type: Union nut · Reserve level: 70 mm

Nut M7 Inox

Nut type: Hexagon nut · Nominal diameter (thread): 7 mm · Drive: External hexagon · Thread type: M7x1 (standard thread) · Height: 5.5 mm · Material: Chrome steel (colloquially known as stainless steel) · Width across flats: 11 mm · Piaggio OEM number: 020107, 1107, 226745

Washer M7 7.4/14/1.6 galvanized

Material: Steel · Surface: galvanized (blue) · Thread size: M7 · Nominal diameter inside: 7 mm · Nominal diameter (thread): 7 mm · Piaggio OEM number: 003057, 3057, S.13842

swiing® ingenious 15 mm carburetor camouflaged | Sachs 503

Manufacturer: swiing® ingenious parts · Material: Aluminum · Area of application: Tuning · Camouflaged: Yes · Component group Carburetor: Carburetor complete · Nominal diameter: 15 mm · Carburetor type: SRE · Nozzle thread: M3.5x0.6 (standard thread) · Mounting type: Plug connection clamped · Nozzle size: 62 · Ø Inside entrance: 15 mm · Ø Internal connection: 20 mm · Total length: 66 mm · Ø Output inside: 15 mm · Width: 50 mm · Ø Air filter connection: 20 mm · Height: 95 mm · Ø fuel hose connection: 6 mm · Mixed oil connection: No · Vacuum connection: No · Choke control: Hand choke · Nozzle block: 2.17 · Clamping screw torque (max.): 4 N/m

Stud bolt M6/M7 x 35 mm (extended) Inlet/outlet

Thread type: M6x1 (standard thread) · Thread type: M7x1 (standard thread) · Surface: burnished · Material: Steel · Nominal diameter (thread): 6 mm · Nominal diameter (thread): 7 mm · Total length: 35 mm

M8x30 stud bolt (inlet/outlet)

Thread type: M8x1.25 (standard thread) · Surface: burnished · Material: Steel · Nominal diameter (thread): 8 mm · Thread length: 10 mm · Total length: 30 mm

Stud bolt inlet/outlet M6/8 x 30 mm

Thread type: M6x1 (standard thread) · Thread type: MF8x1 (fine pitch thread) · Surface: burnished · Material: Steel · Nominal diameter (thread): 6 mm · Nominal diameter (thread): 8 mm · Thread length: 14 mm · Thread length: 16 mm · Total length: 30 mm

Nut M8 high (3D) galvanized

Thread type: M8x1.25 (standard thread) · Surface: galvanized (blue) · Nut type: Hexagon nut · Material: Steel · Nominal diameter (thread): 8 mm · Drive: External hexagon · Height: 25 mm · Width across flats: 13 mm
